The Control Stack

Why this matters: The control stack is the nervous system of a robot. It translates high-level commands ("walk forward") into low-level motor commands (torque values every millisecond).

Introduction: From Intent to Action

When you think "pick up the cup," your brain sends signals through your spinal cord to your muscles. A robot does the same—just with software, math, and electronics.

---

The Control Hierarchy

graph TD
    A[Mission Planner<br/>1 Hz] --> B[Task Planner<br/>10 Hz]
    B --> C[Motion Planner<br/>50 Hz]
    C --> D[Trajectory Controller<br/>200 Hz]
    D --> E[Joint Controller<br/>1000 Hz]
    E --> F[Motor Driver<br/>10000 Hz]

Level	Frequency	Responsibility
Mission	0.1-1 Hz	"Go to kitchen"
Task	1-10 Hz	"Pick up cup, then walk"
Motion	10-100 Hz	"Follow this path"
Trajectory	100-500 Hz	"Track this curve"
Joint	500-2000 Hz	"Servo to this angle"

---

State Machines

Most robot behaviors are organized as state machines:

class RobotStateMachine:
    def __init__(self):
        self.state = 'IDLE'

    def update(self, command, sensors):
        if self.state == 'IDLE':
            if command == 'walk':
                self.state = 'STANDING_UP'

        elif self.state == 'STANDING_UP':
            if sensors.is_upright():
                self.state = 'WALKING'

        elif self.state == 'WALKING':
            if command == 'stop':
                self.state = 'STOPPING'
            if sensors.detected_obstacle():
                self.state = 'AVOIDING'

stateDiagram-v2
    [*] --> IDLE
    IDLE --> STANDING_UP: walk_cmd
    STANDING_UP --> WALKING: upright
    WALKING --> STOPPING: stop_cmd
    WALKING --> AVOIDING: obstacle
    STOPPING --> IDLE: still
    AVOIDING --> WALKING: clear

---

Trajectory Tracking

Reference Trajectories

A trajectory specifies position, velocity, and acceleration over time:

q(t), q̇(t), q̈(t)

Computed Torque Control

Combine inverse dynamics with PD feedback:

def computed_torque_control(q, dq, q_des, dq_des, ddq_des):
    # Position and velocity errors
    e = q_des - q
    de = dq_des - dq

    # Desired acceleration with feedback
    ddq_cmd = ddq_des + Kp @ e + Kd @ de

    # Inverse dynamics
    tau = M @ ddq_cmd + C @ dq + G

    return tau

---

Model Predictive Control (MPC)

The gold standard for complex, constrained systems.

The Optimization Problem

At each timestep, solve:

min sum_{k=0}^{N} ||x_k - x_ref||_Q^2 + ||u_k||_R^2

Subject to:

• Dynamics: x_{k+1} = f(x_k, u_k)
• Constraints: u_min ≤ u_k ≤ u_max

MPC for Walking

def walking_mpc(com_state, footsteps):
    # Predict CoM trajectory over horizon
    horizon = 1.0  # seconds
    dt = 0.01
    N = int(horizon / dt)

    # Decision variables: CoM jerk
    jerk = cp.Variable((N, 2))

    # Integrate to get position
    com_pos = integrate(com_state, jerk, dt)

    # Objective: track reference + minimize jerk
    objective = cp.Minimize(
        cp.sum_squares(com_pos - ref_pos) +
        0.01 * cp.sum_squares(jerk)
    )

    # Constraint: ZMP in support polygon
    zmp = compute_zmp(com_pos, jerk)
    constraints = [in_polygon(zmp[k], support[k]) for k in range(N)]

    problem = cp.Problem(objective, constraints)
    problem.solve()

    return jerk.value[0]  # Apply first command

---

Safety Systems

Layered Safety

graph TD
    A[Software Limits] --> B[Firmware Limits]
    B --> C[Hardware E-Stop]
    C --> D[Physical Structure]

Safe Operating Regions

Define where the robot is allowed to be:

class SafetyMonitor:
    def check_limits(self, state):
        # Joint limits
        for i, q in enumerate(state.joint_positions):
            if q < JOINT_MIN[i] or q > JOINT_MAX[i]:
                return SafetyViolation.JOINT_LIMIT

        # Velocity limits
        for i, dq in enumerate(state.joint_velocities):
            if abs(dq) > VELOCITY_MAX[i]:
                return SafetyViolation.VELOCITY_LIMIT

        # Self-collision
        if self.check_collision(state):
            return SafetyViolation.SELF_COLLISION

        return SafetyViolation.NONE

Never Disable Safety

Production robots have multiple independent safety systems. Never disable them "for testing." Use separate debug modes with different limits.

---

Real-Time Considerations

Determinism

Control code must complete in bounded time:

Component	Max Latency
Joint controller	100 μs
Trajectory controller	1 ms
Motion planner	10 ms
Task planner	100 ms

RT-PREEMPT Linux

Patches for real-time Linux:

# Check real-time priority
chrt -p $$

# Run with real-time priority
sudo chrt -f 99 ./controller

---

Key Takeaways

Summary

1. Control is hierarchical: high-level to low-level
2. State machines organize behavior
3. MPC optimizes over future trajectories
4. Safety must be layered and independent
5. Real-time constraints are non-negotiable

---

Further Reading

• Chapter 3.1: ROS 2 Concepts
• Chapter 3.3: Perception
• Chapter 2.2: Actuation & Control
